12V~240V Aluminum Nitride Ceramic Heaters
GREENWAY is a professional Advanced 12V~240V Aluminum Nitride Ceramic Heaters manufacturer and supplier in China. We have been specialized in AIN Ceramic Heaters solutions more than 10 years. Besides our existing MCH ceramic heating elements, we also provide customized AIN ceramic heaters solutions and services to meet customer different needs according to customers' drawings or samples under the assistance of our own R&D team.
Send Inquiry
Product Description
Advanced Aluminum Nitride Ceramic Heaters are constructed of aluminum nitride (AlN) and incorporate a thermally matched proprietary heating element that provides maximum performance in challenging applications.
Advanced Aluminum Nitride Ceramic Heaters is especially suitable for applications requiring a clean, non-contaminating heat source. Additionally, the excellent geometric stability ensures consistent part-to-part thermal contact during heating cycles.
GREENWAY Advanced Aluminum Nitride Ceramic Heaters can operate up to 400°C (752°F) with an ultra-fast ramp rate of up to 150°C (270°F) per second depending on the application, heater design and process parameters. In addition to excellent thermal characteristics, AIN ceramic heaters have high electrical isolation and typically provides superior chemical resistance as compared to traditional metal heaters.
Advanced 12V~240V Aluminum Nitride Ceramic Heaters thermal and Physical Properties
|
Thermal Properties |
Physical Properties |
||
|
TCR |
1.5*10-3/℃ |
Hardness |
1050 Hv/500g |
|
Surfaced Temperature |
600℃（1112°F） |
Flexural strength |
＞250MPaTher |
|
Terminal Temperature |
400℃（775°F） |
|
|
AIN Advanced Ceramic Heaters Benefit
Ultra-fast ramp rates
High watt densities
Low leakage current
Advanced Aluminum Nitride Ceramic Heaters Specification
|
Shape |
Dimension(mm) Length*Width*Thickness |
Working Volatge(V) |
Power(W) |
Power density(W/cm²) |
|
Square |
19*19.*2.5 |
220 |
200 |
55.56 |
Contact us for more models or customization.
