300W Black Quartz Crystal Ignition for Biomass Boiler

GREENWAY is a manufacturer and supplier of Quartz Crystal (Silicon Nitride) and aluminum Ignition. The Quartz Crystal Ignition (Silicon Nitride) from GREENWAY can quickly reach temperatures of 800°C to 1200°C within seconds. It ignites fuel either through direct heat transfer or forced air heating.

Generally working voltage is AC220-240V~.

Custom size from 200mm x 200mm are available.

300W Black Quartz Crystal Ignition for Biomass Boiler Features

Miniaturization, high temperature resistance

Higher power density,

Working temperature can reach 800℃~1200℃.

Fast heating- 800℃~1200℃ within 20~50S.

Good stability

Good electrical insulation performance, excellent voltage resistance, resistance will not age, no power decay.

Specification of 300W Black Quartz Crystal Ignition for Biomass Boiler:

Precautions when using 300W Black Quartz Crystal Ignition for Biomass Boiler

This product is for industrial use only.

Use a variable transformer to perform voltage control or use a temperature controller to implement temperature control.

Use the heater under atmospheric pressure in the air.

Do not apply excessive external forces (tension, bending, etc.) to the lead wire joint.

Since the heater material is silicon nitride (ceramics), please handle carefully, as it may crack if you drop it or hit it.

Please fix the insulator part for attaching the heater.　Also, please be careful as overtightening may cause damage.

Application of 300W Black Quartz Crystal Ignition for Biomass Boiler Ignition

• Biomass boiler igniter, straw incinerator igniter

• Biomass steam generator igniter

• Biomass burner igniter

• Hot air gun, ignition gun, welding gun

• Fireplace igniter

• Firework generator igniter

• Barbecue charcoal igniter

• Oil and gas igniter

Inquiry about Quartz Crystal Ignition for Biomass Boiler

All products listed are available in different voltages.

Please contact us for a custom designed quote and/or for any questions about our products.

Quartz Crystal Ignition Ignition Customized Service

Customization is available and welcome in our company, Please contact customer service directly.
