Long life Ceramic Ozone Plates for Air Purifier

GREENWAY company is a large-scale Ceramic Ozone Plates manufacturer and supplier in China. 92% black alumina ceramic sintered at a high temperature of 1650°C, which has the characteristics of high thermal conductivity, good shock resistance, pollution resistance, long life, and high dielectric strength.

Long life Ceramic Ozone Plates for Air Purifier parameter:

It can be used in vehicle or other types of DC,AC power, working voltage 4.5kv, frequency 25-30hz, different specifications power is different, and the power of the film can be constant after two hours.

Ozone Output: 800mg/h or accordingly

Input Voltage: AC12V +/-10%

Output Voltage: 3.1kv-4.5kv

Power Consumption: 100W

Gas Feeding: Dry Air or Oxygen

Ozone Generating Method: Corona Discharge

Cooling Method: Ambient Air Cooling

Working Principle of Ceramic Ozone Plates for Air Purifier:

Take advantage of high voltage, use dry air or oxygen in the air as raw material to produce O3

Working Notice of Ceramic Ozone Plates for Air Purifier:

1. When using this ozone generator, better to use an electrical fan. and strictly forbid people working in the room with ozone in high concentration. The output high voltage is dangerous. you are strictly forbidden to touch it in any way when it is working.

2. Clean the ceramic plate with ethyl alcohol every month, and use it when it fully dry. In this way, to guarantee normal ozone yield.
